HCZ系列化工流程泵 / HCZ Series

HCZ系列耐腐蚀化工流程泵性能参数表(3)
发布时间:2019-10-26 浏览次数：1816



规格
性能参数
配用电机（按照介质比重）
汽蚀余量
m req
进口法兰直径

转速

r/min

叶轮型式

流量

(m3/h)

扬程

(m)

效率

%

轴功率

kw

γ=1.0
γ=1.35
γ=1.84
50-200
1450
A
34
13
70
1.72
Y100L-4/2.2
Y100L2-4/3
Y112M-4/4
1.5
80
B
34
11
70
1.45
Y90L-4/1.5
Y100L1-4/2.2
Y100L2-4/3
C
30
9
70
1.05
Y90L-4/1.5
Y90L-4/1.5
Y100L1-4/2.2
D
24
7
70
0.65
Y802-4/0.75
Y90S-4/1.1
Y90L-4/1.5
2900
A
65
54
72
13.27
Y160M2-2/15
160L-2/18.5
Y200L1-2/30
2
80
B
65
46
72
11.3
Y160M2-2/15
160L-2/18.5
Y180M-2/22
C
50
37
72
6.99
Y132S1-2/7.5
Y160M1-2/11
Y160M2-2/15
D
40
29
72
4.39
Y132S1-2/5.5
Y132S2-2/7.5
Y160M1-2/11
50-250
1450
A
34
20
59
3.14
Y112M-4/4
Y132S-4/5.5
Y132SM-4/7.5
1.1
80
B
30
19
59
2.63
Y100L2-4/3
Y112M-4/4
Y132S-4/5.5
C
26
15
59
1.8
Y100L1-4/2.2
Y100L2-4/3
Y112M-4/4
D
24
11
59
1.22
Y90L-4/1.5
Y100L1-4/2.2
Y100L2-4/3
2900
A
65
81
64
22.39
Y200L1-2/30
Y200L2-2/37
Y225M-2/45
2.5
80
B
60
76
64
19.39
Y180M-2/2.2
Y200L1-2/30
Y200L2-2/37
C
55
64
64
14.97
Y160M2-2/15
Y180M-2/22
Y200L1-2/30
D
45
56
64
10.72
Y160M2-2/15
Y160M2-2/15
Y180M-2/22
50-315
1450
A
42
36
58
7.1
Y132M-4/7.5
Y160M-4/11
Y160L-4/15
1.8
80
B
42
32
58
6.31
Y132M-4/7.5
Y160M-4/11
Y160L-4/15
C
40
26
58
4.88
Y132S-4/5.5
Y132M-4/7.5
Y160M-4/11
D
36
20
58
3.38
Y112M-4/4
Y132S-4/5.5
Y132M-4/7.5
2900
A
80
140
60
80.81
Y250M-2/55
Y280S-2/75
Y315S-2/110
2.4
80
B
75
135
60
47.52
Y250M-2/55
Y280S-2/75
Y280M-2/90
C
70
110
60
34.94
Y200L2-2/37
Y250M-2/55
Y280S-2/75
D
65
85
60
25.07
Y200L1-2/30
Y200L2-2/37
Y250M-2/55
65-160
1450
A
50
8
68
1.6
Y100L1-4/2.2
Y100L2-4/3
Y112M-4/4
1.5
100
B
48
7
68
1.35
Y90L-4/1.5
Y100L1-4/2.2
Y100L2-4/3
C
46
6
68
1.1
Y90L-4/1.5
Y100L1-4/2.2
Y100L1-4/2.2
D
38
4
68
0.61
Y802-4/0.75
Y90L-4/1.5
Y90L-4/1.5
2900
A
100
32
74
11.77
Y160M2-2/15
Y160L-2/18.5
Y180M-2/22
2.3
100
B
90
32
74
10.59
Y160M1-2/11
Y160M2-2/15
Y180M-2/22
C
90
24
74
7.95
Y160M1-2/11
Y160M2-2/15
Y160M2-2/15
D
80
14
74
4.38
Y132S1-2/5.5
Y132S2-2/7.5
Y160M1-2/11
65-200
1450
A
50
13
73
2.42
Y100L2-4/3
Y112M-4/4
Y132S-4/5.5
1
100
B
46
12
73
2.06
Y100L1-4/2.2
Y100L2-4/3
Y112M-4/4
C
42
10
73
1.57
Y100L1-4/2.2
Y100L2-4/3
Y112M-4/4
D
36
7
73
0.94
Y90S-4/1.1
Y90L-4/1.5
Y100L1-4/2.2
2900
A
100
54
73
20.14
Y180M-2/22
Y200L1-2/30
Y200L2-2/37
3.2
100
B
90
50
73
16.78
Y160L-2/18.5
Y200L1-2/30
Y200L2-2/37
C
90
40
73
13.42
Y160M2-2/15
Y180M-2/22
Y200L1-2/30
D
70
30
73
7.83
Y160M1-2/11
Y160M2-2/15
Y160M2-2/15
